Essex engine made in New Brunswick

Old Marine Engine » One and Two Cylinder Gas Inboards » Essex engine made in New Brunswick « Previous Next »

Author Message
Top of pagePrevious messageNext messageBottom of page Link to this message

mechman
Member
Username: mechman

Post Number: 12
Registered: 10-2003


Posted on Saturday, October 13, 2007 - 10:06 am:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

Goodday I now have the Essex restored for your pleasure--modified a crankshaft from an Acadia salt water junker & also used the con rod (same lenght & stroke)--here are some photos Email me if you want more detail mechman@nexicom.netname plateside viewother sidewith flywheel removed
Top of pagePrevious messageNext messageBottom of page Link to this message

richarddurgee
Senior Member
Username: richarddurgee

Post Number: 1548
Registered: 11-2001
Posted on Saturday, October 13, 2007 - 03:34 pm:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

*

Larry - Really nice restoration and I'm sure its worth all your time and effort.

Haven't seen many of these old timers around ! have you run it yet ?

*
Top of pagePrevious messageNext messageBottom of page Link to this message

richardday
Senior Member
Username: richardday

Post Number: 522
Registered: 11-2003


Posted on Saturday, October 13, 2007 - 03:43 pm:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

Very nice work. Congratulations.
Top of pagePrevious messageNext messageBottom of page Link to this message

richarddurgee
Senior Member
Username: richarddurgee

Post Number: 1549
Registered: 11-2001
Posted on Saturday, October 13, 2007 - 03:52 pm:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

*
June 1906 Essex ad

e06

*
Top of pagePrevious messageNext messageBottom of page Link to this message

mechman
Member
Username: mechman

Post Number: 13
Registered: 10-2003


Posted on Saturday, October 13, 2007 - 08:38 pm:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

Goodday again Many thanks for the kind comments---as it stands it's only a static display--it will need more work to become a runner (But not that much)I hoping to see anything in Canadian info--ads or sales literature
Top of pagePrevious messageNext messageBottom of page Link to this message

thomas
Senior Member
Username: thomas

Post Number: 272
Registered: 07-2002


Posted on Thursday, October 18, 2007 - 07:56 pm:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

Larry,

Great looking job. It's a handfull as I recall.
Why did you replace crankshaft?
Tom
Top of pagePrevious messageNext messageBottom of page Link to this message

mechman
Member
Username: mechman

Post Number: 14
Registered: 10-2003


Posted on Tuesday, October 23, 2007 - 08:46 am:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

Goodday Tom The crankpin was in bad shape --I figured it would be easier to take an Acadia Shaft ( I had a salt water junker) & add about 4" to it & as it was a larger diameter we cleaned out the bore of the brass bearings & turned it to fit--This meant also oversizing the flywheel bore ,so now it's just like a new engine on the bottom end.
