Help Identify Engines... I am new to ...

Old Marine Engine » Unknown Engines - post here with photos » Help Identify Engines... I am new to hobby of collecting. « Previous Next »

Author Message
Top of pagePrevious messageNext messageBottom of page Link to this message

Tom Williams
New member
Username: charliehustle

Post Number: 2
Registered: 01-2023
Posted on Wednesday, January 18, 2023 - 06:45 am:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

I just purchased my first marine engines and need help identifying make and model... please forward any information to aid with restoring or a contact for parts.
Small Engine with casing around cylinder.
Small Engine with casing around cylinder.
Top of pagePrevious messageNext messageBottom of page Link to this message

miro forest
Senior Member
Username: miro

Post Number: 1212
Registered: 11-2001


Posted on Thursday, January 19, 2023 - 03:22 pm:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

This looks like a "knock-off" copy of a Waterman copper jacket engine.
The crankcase casting, the intake and exhaust ports look the same, the water pump looks the same, the primer cup and location on the cylinder is the same, the flywheel and nut on the flywheel are the same.

But the cylinder and the timer are different. But it's headless engine just like the copper jacket engine.

The water circulates by being pumped into the water jacket , swirls around the cylinder, and the goes out via an over flow pipe inside the water jacket space near the top of the cylinder.

The Waterman copper jacket engines are fairly common and certainly not rare. Many are still in use in DisPro boats today.

Is the water jacket a copper or brass cylinder?

Like your St Lawrence engine, this engine will need a buzz coil type of ignition and needs a gas/oil mix ( 25:1) .
miro
Top of pagePrevious messageNext messageBottom of page Link to this message

Tom Williams
Member
Username: charliehustle

Post Number: 5
Registered: 01-2023
Posted on Saturday, January 21, 2023 - 07:09 am:   Edit Post Delete Post View Post/Check IP Print Post    Move Post (Moderator/Admin Only)

Hello Miro...
Thank you for your reply...
I believe the water jacket is copper... what size or type carburetor will this engine require...?
Am I missing other parts and who do you recommend to contact for locating these parts...?
How does the ignition connect to this engine...?
Thank You... Tom.
